Stainless steel wire mesh
Material: 304 304L 316 316L. Weaving: plain weave, twill weave, (plain/twill) mat dense weave. Mesh: 1 mesh - 2800 mesh.
Like this product? Share with friends:
Products Details

Type 304 generally refers to "18-8" (18% chromium, 8% nickel) and is mostly a basic stainless steel alloy that is ideal for mesh. It can be exposed to the outdoors and will not rust or oxidize when the outside temperature rises to 1400 degrees Fahrenheit.

 Type 304L is very similar to T-304, except that it has a reduced carbon content and is easier to braiding and re-welding.

 Type 316 can be stabilized by the addition of 2% molybdenum, and T-316 is an "18-8" alloy. It is less susceptible to corrosion in brine, sulphur or halide salts than other chromium-nickel stainless steels. Chloride, for example, is an obvious example. The most valuable feature of T-316 is that it has greater creep resistance at rising temperatures. Other mechanical and structural characteristics are the same as those of the T-304.

 Type 316L is very similar to T-316, except that it has a reduced carbon content and is easier to weave and reweld.

Performance: strong resistance to acid, alkali, high temperature, tensile and abrasion.

Uses: Stainless steel wire mesh and stainless steel cloth are widely used in screening and filtration under acid and alkali environmental conditions, mud mesh in the petroleum industry, sieve filter screen in the chemical fiber industry, environmental protection, minerals, aviation field, paper industry, electronics, metallurgy, electroplating industry as pickling net, etc. The company can design and produce various types of products according to user needs, and the size and specifications can be determined according to the special requirements of customers.



Mesh



Wire diameter

Opening

OPENING AREA

WEIGHT(LB)/100 SQUARE FEET

INCH

MM

INCH

MM

1x1

0.08

2.03

0.92

23.37

84.6

41.1

2X2

0.063

1.6

0.437

11.1

76.4

51.2

3X3

0.054

1.37

0.279

7.09

70.1

56.7

4X4

0.063

1.6

0.187

4.75

56

104.8

4X4

0.047

1.19

0.203

5.16

65.9

57.6

5X5

0.041

1.04

0.159

4.04

63.2

54.9

6X6

0.035

0.89

0.132

3.35

62.7

48.1

8X8

0.028

0.71

0.097

2.46

60.2

41.1

10X10

0.025

0.64

0.075

1.91

56.3

41.2

10X10

0.02

0.51

0.08

2.03

64

26.1

12X12

0.023

0.584

0.06

1.52

51.8

42.2

12X12

0.02

0.508

0.063

1.6

57.2

31.6

14X14

0.023

0.584

0.048

1.22

45.2

49.8

14X14

0.02

0.508

0.051

1.3

51

37.2

16X16

0.018

0.457

0.0445

1.13

50.7

34.5

18X18

0.017

0.432

0.0386

0.98

48.3

34.8

20X20

0.02

0.508

0.03

0.76

36

55.2

20X20

0.016

0.406

0.034

0.86

46.2

34.4

24X24

0.014

0.356

0.0277

0.7

44.2

31.8

30X30

0.013

0.33

0.0203

0.52

37.1

34.8

30X30

0.012

0.305

0.0213

0.54

40.8

29.4

30X30

0.009

0.229

0.0243

0.62

53.1

16.1

35X35

0.011

0.279

0.0176

0.45

37.9

29

40X40

0.01

0.254

0.015

0.38

36

27.6

50X50

0.009

0.229

0.011

0.28

30.3

28.4

50X50

0.008

0.203

0.012

0.31

36

22.1

60X60

0.0075

0.191

0.0092

0.23

30.5

23.7

60X60

0.007

0.178

0.0097

0.25

33.9

20.4

70X70

0.0065

0.165

0.0078

0.2

29.8

20.8

80X80

0.0065

0.165

0.006

0.15

23

23.2

80X80

0.0055

0.14

0.007

0.18

31.4

16.9

90X90

0.005

0.127

0.0061

0.16

30.1

15.8

100X100

0.0045

0.114

0.0055

0.14

30.3

14.2

100X100

0.004

0.102

0.006

0.15

36

11

100X100

0.0035

0.089

0.0065

0.17

42.3

8.3

110X110

0.004

0.1016

0.0051

0.1295

30.7

12.4

120X120

0.0037

0.094

0.0064

0.1168

30.7

11.6

150X150

0.0026

0.066

0.0041

0.1041

37.4

7.1

160X160

0.0025

0.0635

0.0038

0.0965

36.4

5.94

180X180

0.0023

0.0584

0.0033

0.0838

34.7

6.7

200X200

0.0021

0.0533

0.0029

0.0737

33.6

6.2

250X250

0.0016

0.0406

0.0024

0.061

36

4.4

270X270

0.0016

0.0406

0.0021

0.0533

32.2

4.7

300X300

0.0051

0.0381

0.0018

0.0457

29.7

3.04

325X325

0.0014

0.0356

0.0017

0.0432

30

4.4

400X400

0.001

0.0254

0.0015

0.37

36

3.3

500X500

0.001

0.0254

0.001

0.0254

25

3.8

635X635

0.0008

0.0203

0.0008

0.0203

25

2.63
